Pinfire Revolvers Explained
Price :
7.95 US $


Download URL for manual installation
Click on the line above

Download URL for automatic installation
Click on the line above


Version for Android mobile devices






Ebook's Content


Dismounting an open-frame pinfire revolver (I)

- Generalities about pinfire revolvers
- Removal of the ejection rod
- Removal of the barrel

Dismounting an open-frame pinfire revolver (II)

- Removal of the cylinder
- Dismounting of the loading gate
- Removal of the trigger guard and trigger spring
- Removal of the cylinder arbor and friction spring

Dismounting an open-frame pinfire revolver (III)

- Access to the mainspring
- Dismounting of the hammer
- Dismounting of the trigger assembly
- Reassembly tips

Functioning of an open-frame pinfire revolver

- Cartridge loading
- Vintage 9mm pinfire cartridges
- Firing in double action mode
- Firing in single action mode
- Cylinder rotation
- Cylinder stop
- Front and rear sight
- No safety system available

Open-frame pinfire revolver of large caliber

- Various types of 12mm pinfire cartridges
- Structural flaw of the open-frame design
- Removal of the mainspring

Innovative open-frame pinfire revolver by Maurice Arendt (I)

- Loading gate of unusual design
- Hammer with narrow head
- Unusual cylinder stop abutments
- Safety lever on the front grip strap

Innovative open-frame pinfire revolver by Maurice Arendt (II)

- Unusual cylinder arbor leaf spring
- Counterbored chambers
- Dual ignition system
- Functioning of the Arendt grip safety
- Other safety by Maurice Arendt

First step toward the solid-frame construction

- Semi solid-frame pinfire revolver
- Dismounting of the barrel
- Protecting shield
- Integral front and rear sights
- Top strap integral with the barrel

Solid-frame pinfire revolver in 7mm caliber

- Design without pivoting loading gate
- Dismounting of the cylinder
- Internal mechanism
- Eugène Lefaucheux folding trigger

Modified solid-frame pinfire revolver of English design (I)

- Initially fitted with longer barrel and grip
- Dismounting of the ejector rod
- Dismounting of the cylinder
- Access to the mainspring
- Adams construction of the grip

Modified solid-frame pinfire revolver of English design (II)

- Dismounting of the hammer and safety
- Dismounting of the trigger assembly
- Dismounting of the V shaped mainspring

Modified solid-frame pinfire revolver of English design (III)

- The hammer safety explained
- Detailed functioning of the hammer safety
- Other models with the same type of safety

Current prices of pinfire civilian revolvers

How to revive your vintage pinfire handguns
